VIP Printer

Rotogravure Printing System for Tablets & Capsules

This precision-driven rotogravure printing system is a great option for pharmaceutical and confectionery products. The machine features a single-lane carrier timing belt feed system that exposes both sides of your product for inspection and ink printing. The VIP Printer effortlessly continues operation with minimal user interaction or downtime and requires only compressed air and power for operation.

Output up to 60,000 PPH One or Two-Sided Rotogravure Printing

stainless steel VIP ink printer pictured facing right with a clear background

Machine Features

Single-lane carrier link system
Safety enclosure with interlocked doors
Servo based motion with optical encoder position feedback
Carrier timing belt with precision machined pockets
Tool-free installation of carrier links
Adjustable hopper assembly for quick changeover between products
Patented hopper air-assist feature & clean air filtration system
Articulated swing arm with 17” touch-screen HMI
Programmable settings for up to 50 products
Portable with a small footprint

Capabilities

Output Up to 60,000 PPH
Single or Double Sided Printing with independent graphics for each side
Single-Sided marking using time proven rotogravure printing
Ability to print alpha-numeric text or graphic logos
Ability to print with solvent or water-based ink solutions
Ability to print in multiple ink colors

A glass bottle tipped over, spilling numerous round yellow pills with black "93 64" capsule printing with a white background.

Options

Vision inspection with vacuum-based single product rejection
OPC-UA Server Gateway
HMI screen text translated and displayed in language of choice
Secure remote support capabilities
Auto-backup of product settings

Safety & Regulatory Compliance

cGMP for Pharmaceuticals
FDA 21 CFR Compliance:
- Part 210
- Part 211
- Part 11
CE Compliant
NFPA 79
IEC / EN 60204-1
ISO 13849-1
CRC, c 870
CDRH Compliant

View our FDA & CE Compliance page

Engineered for Performance You Can Trust

Proudly made in the USA, our machines are built for simplicity and reliability, featuring a user-friendly interface, low maintenance costs, and an included toolkit. With worldwide customer support, you can trust Ackley Hartnett to provide reliable performance and help when you need it.
