IBM Ink Printer

Flatbed Printing System for Tablets & Capsules

The IBM Ink Printing Machine is our high-speed, large scale production printing machine. With outputs over 300,000 pieces per hour, the IBM prints all tablets, soft gelatin capsules, and caplets with ease. This flatbed machine comes with a bulk hopper and flood feeder for maximum fill rates and can print one side of a tablet.

Up to 300,000 PPH Single-Sided Flatbed Printing

Machine Features

Single-sided printing
Adjustable hopper for maximum fill rate
Servo drive system for precision print registration
Quick change carrier bar tooling
Swingarm 15” touch screen HMI
Wi-Fi connectivity
Batch recording
Data transfer capability
21 CFR Part 11 Compliant
CE and UL certified

Capabilities

Output up to 300,000 PPH
Single-Sided Marking with independent graphics
Print alpha-numeric text, vector graphics, logos
Graphics editing software provided
Adjustable parameters to control logo size, line width
Mark Bi-Color products with logo oriented on selected color side
Orient logos based on product feature, such as tablet bisect line

A variety of colorful prescription pills and capsules, highlighting Ackley Hartnett capabilities, are spilled from a bottle onto a white background. The pills display different shapes, colors, sizes, and visible imprints or codes.

Options

Vision inspection system with single piece rejection
Ink Viscosity System
Rubber Roll Cleaning System
Validation document packages available
Floor level infeed bulk conveyor

Safety & Regulatory Compliance

We adhere to or surpass the strictest regulations set forth by the Food and Drug Administration (FDA) and their approach to Current Good Manufacturing Practice (CGMP) regulations.

cGMP for Pharmaceuticals
FDA 21 CFR Compliance:
- Part 210
- Part 211
- Part 11
CE Compliant
NFPA 79
IEC / EN 60204-1
ISO 13849-1
CRC, c 870
CDRH Compliant

View our FDA & CE Compliance page

Engineered for Performance You Can Trust

Proudly made in the USA, our machines are built for simplicity and reliability, featuring a user-friendly interface, low maintenance costs, and an included toolkit. With worldwide customer support, you can trust Ackley Hartnett to provide reliable performance and help when you need it.
